KO-1G

Product Description

Technical data	KO-1G	KO-2G	KO-1P	KO-2P	ΚΟ-9P	KO-10P
Connector type	BNC	BNC	BNC	BNC	F	ΤV
Max continuous operating voltage	72 V	200 V	72 V	200 V	72 V	72 V
Nominal current	2,5 A	2,5 A	2,5 A	2,5 A	0,5 A	0,5 A
D1 Max. lighting impulse current (10/350)	2 kA	2 kA	2 kA	2 kA	2 kA	2 kA
C2 Max discharge current (8/20)	10 kA	10 kA	10 kA	10 kA	10 kA	10 kA
C2 Nominal discharge current (8/20)	5 kA	5 kA	5 kA	5 kA	5 kA	5 kA
Voltage protection level at 1 kV/μs	500 V	600 V	500 V	600 V	500 V	500 V
Frequency range	0-1 GHz	0-1 GHz	0-1 GHz	0-1 GHz	0-2 GHz	0-1 GHz
Max. transmission power capacity	50 W	400 W	50 W	400 W	50 W	50 W
Insertion loss	<0,2 dB	<0,2 dB	<0,2 dB	<0,2 dB	<0,5 dB	<1,2 dB
Return loss	>20 dB	>20 dB	>20 dB	>20 dB	>20 dB	>20 dB
Characteristic impedance	50 Ω	50 Ω	50 Ω	50 Ω	75 Ω	75 Ω
Category tested acc. To IEC 61643:21-2000	A2, B2, C2, C3,D1	A2, B2, C2, C3,D1	A2, B2, C2, C3,D1	A2, B2, C2, C3,D1	A2, B2, C2, C3,D1	A2, B2, C2, C3,D1
