Product Description

Technical data

KO-3GN(F/F)

KO-3GN(F/M)

KO-4GN(F/F)

KO-4GN(F/M)

KO-5GN(F/F)

KO-5GN(F/M)

KO-6GN(F/M)
Connector  type

N

N

N

N

N

N

N
Max continuous operating voltage

72 V

72 V

200 V

200 V

-

-

135 V
Nominal  current

5 A

5 A

5 A

5 A

-

-

5 A
D1 Max. lighting impulse current (10/350)

2 kA

2 kA

2 kA

2 kA

5 kA

5 kA

1 kA
C2 Max discharge current (8/20)

10 kA

10 kA

10 kA

10 kA

20 kA

20 kA

10 kA
C2 Nominal discharge current (8/20)

5 kA

5 kA

5 kA

5 kA

10 kA

10 kA

5 kA
Voltage protection level at 1 kV/μs

500 V

500 V

600 V

600 V

<2 V

<2 V

<500 V
Frequency range

0-3 GHz

0-3 GHz

0-3 GHz

0-3 GHz

5-5,4 GHz

5-5,4 GHz

0-5,8 GHz
Max. transmission power capacity

50 W

50 W

400 W

400 W

200 W

200 W

50 W
Insertion loss

<1,5 dB

<1,5 dB

<1,5 dB

<1,5 dB

<0,2 dB

<0,2 dB

<0,2 dB
Return loss

>20 dB

>20 dB

>20 dB

>20 dB

>20 dB

>20 dB

>20 dB
Characteristic impedance

50 Ω

50 Ω

50 Ω

50 Ω

50 Ω

50 Ω

50 Ω
Category tested acc. To IEC 61643:21-2000

A2, B2, C2, C3,D1

A2, B2, C2, C3,D1

A2, B2, C2, C3,D1

A2, B2, C2, C3,D1

A2, B2, C2, C3,D1

A2, B2, C2, C3,D1

A2, B2, C2, C3,D1
