Spel Solutions - PI-3k120

WITH EMC / EMI FILTER two stauge MOV surge arrester & EMC/EMI filter (3~)

U_N=230/400V
I_N=120A, In(8/20)=3kA(L/N,L/PE), 5kA(N/PE), UOC=6kV(L/N, L/PE), 10kV(N/PE)
U_P(Uoc)<850V(L/N), <1,5kV(L/PE), <0,5kV(N/PE)
