Product Description

Technical data

Number of protected pairs

H30/6

1

H30/12

1

H30-24

1

H30-L/6

1

H30-L/12

1

H30-L/24

1

H30-L/12

1
Connector  type

BNC(F/F, F/M)

BNC(F/F, F/M)

BNC(F/F, F/M)

BNC(F/F, F/M)

BNC(F/F, F/M)

BNC(F/F, F/M)

BNC(F/F, F/M)
Nominal  voltage

6 V

12 V

24 V

6 V

12 V

24 V

12 V
Max continuous operating voltage

7,2 V

14,4 V

28,8 V

7,2 V

14,4 V

28,8 V

14,4 V
Nominal  current

300 mA

300 mA

300 mA

300 mA

300 mA

300 mA

300 mA
C2 Max discharge current (8/20)

5 kA

5 kA

6,5 kA

6,5 kA

6,5 kA

6,5 kA

6,5 kA
C2 Nominal discharge current (8/20)

1 kA

1kA

1 kA

1 kA

1kA

1 kA

1kA
Voltage protection level at In

22 V

44 V

22 V

22 V

44 V

22 V

44 V
Voltage protection level at 1 kV/μs

10 V

20 V

10 V

10 V

20 V

10 V

20 V
Response time

<30 ns

<30 ns

<30 ns

<30 ns

<30 ns

<30 ns

<30 ns
Parasitic capacitance

<27 pF

<27 pF

<27 pF

<27 pF

<27 pF

<27 pF

<27 pF
Series impedance per line

10 Ω

10 Ω

10 Ω

10 Ω

10 Ω

10 Ω

10 Ω
Operating temperature range

-40oC÷ +80oC

-40oC÷ +80oC

-40oC÷ +80oC

-40oC÷ +80oC

-40oC÷ +80oC

-40oC÷ +80oC

-40oC÷ +80oC
Category tested acc. To IEC 61643:21-2000

A2, B2, C2, C3,D1

A2, B2, C2, C3,D1

A2, B2, C2, C3,D1

A2, B2, C2, C3,D1

A2, B2, C2, C3,D1

A2, B2, C2, C3,D1

A2, B2, C2, C3,D1
